Категория
Transistors - FETs, MOSFETs - Single
Производитель
LAPIS Technology
RoHS
YES
Certification
Доставка
Оплата
| TYPE | DESCRIPTION |
| Part Number: | RCJ120N25TL |
| Description: | MOSFET N-CH 250V 12A LPT |
| Lead Free Status / RoHS Status: | |
| Other Names | RCJ120N25TLTR |
| Current - Continuous Drain (Id) @ 25°C | 12A (Tc) |
| Technology | MOSFET (Metal Oxide) |
| Packaging | Tape & Reel (TR) |
| Series | - |
| Detailed Description | N-Channel 250V 12A (Tc) 1.56W (Ta), 40W (Tc) Surface Mount LPTS (SC-83) |
| Mounting Type | Surface Mount |
| Drain to Source Voltage (Vdss) | 250V |
| Supplier Device Package | LPTS (SC-83) |
| Package / Case | TO-263-3, D²Pak (2 Leads + Tab), TO-263AB |
| FET Feature | - |
| Rds On (Max) @ Id, Vgs | 235 mOhm @ 6A, 10V |
| Vgs(th) (Max) @ Id | 5V @ 1mA |
| Power Dissipation (Max) | 1.56W (Ta), 40W (Tc) |
| Manufacturer Standard Lead Time | 17 Weeks |
| Vgs (Max) | ±30V |
| Gate Charge (Qg) (Max) @ Vgs | 35nC @ 10V |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Operating Temperature | 150°C (TJ) |
| FET Type | N-Channel |
| Input Capacitance (Ciss) (Max) @ Vds | 1800pF @ 25V |
| Drive Voltage (Max Rds On, Min Rds On) | 10V |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Meta Part Number | RCJ120N25TLTR-ND |
Таблицы данных: Work in prgress, stay tuned!
