| TYPE | DESCRIPTION |
| Part Number: | MIC2004-0.8YML-TR |
| Description: | IC DISTRIBUTION SW 0.8A 2X2-MLF |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Features | Load Discharge |
| Interface | On/Off |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Number of Outputs | 1 |
| Ratio - Input:Output | 1:1 |
| Series | - |
| Meta Part Number | MIC2004-0.8YML-TR-ND |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Voltage - Supply (Vcc/Vdd) | Not Required |
| Fault Protection | Current Limiting (Fixed), Over Temperature |
| Manufacturer Standard Lead Time | 5 Weeks |
| Other Names | MIC2004-0.8YML TR "######"MIC2004-0.8YML TR-ND "######"MIC2004-0.8YMLTR "######"MIC2004-0.8YMLTR-ND |
| Voltage - Load | 2.5 V ~ 5.5 V |
| Output Configuration | High Side |
| Switch Type | General Purpose |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Output Type | P-Channel |
| Current - Output (Max) | 800mA |
| Packaging | Tape & Reel (TR) |
| Input Type | Non-Inverting |
| Base Part Number | MIC2004 |
| Rds On (Typ) | 70 mOhm |
| Package / Case | 6-VDFN Exposed Pad, 6-MLF® |
| Supplier Device Package | 6-MLF® (2x2) |
