Категория
Embedded - Microcontrollers
Производитель
Renesas Electronics Corporation
RoHS
YES
Certification
Доставка
Оплата
| TYPE | DESCRIPTION |
| Part Number: | DF2117RVLP20HV |
| Description: | IC MCU 16BIT 160KB FLASH 145LGA |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Detailed Description | H8S/2600 H8® H8S/2100 Microcontroller IC 16-Bit 20MHz 160KB (160K x 8) FLASH 145-TFLGA (9x9) |
| Data Converters | A/D 16x10b |
| Series | H8® H8S/2100 |
| Speed | 20MHz |
| Oscillator Type | External |
| Core Processor | H8S/2600 |
| Program Memory Type | FLASH |
| Package / Case | 145-TFLGA |
| Meta Part Number | DF2117RVLP20HV-ND |
| Connectivity | FIFO, I²C, LPC, SCI, SmartCard |
| Peripherals | POR, PWM, WDT |
| EEPROM Size | - |
| Supplier Device Package | 145-TFLGA (9x9) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Base Part Number | DF2117R |
| Core Size | 16-Bit |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) |
| Voltage - Supply (Vcc/Vdd) | 3 V ~ 3.6 V |
| Operating Temperature | -20°C ~ 75°C (TA) |
| Program Memory Size | 160KB (160K x 8) |
| Packaging | Tray |
| RAM Size | 8K x 8 |
| Number of I/O | 112 |
Таблицы данных: Work in prgress, stay tuned!
