Категория
Diodes - Rectifiers - Single
Производитель
Electro-Films (EFI) / Vishay
RoHS
YES
Certification
Доставка
Оплата
| TYPE | DESCRIPTION |
| Part Number: | 1N5618GPHE3/54 |
| Description: | DIODE GEN PURP 600V 1A DO204AC |
| Lead Free Status / RoHS Status: | |
| Meta Part Number | 1N5618GPHE3/54-ND |
| Speed | Standard Recovery >500ns, > 200mA (Io) |
| Packaging | Tape & Reel (TR) |
| Package / Case | DO-204AC, DO-15, Axial |
| Series | SUPERECTIFIER® |
| Base Part Number | 1N5618 |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Reverse Recovery Time (trr) | 2µs |
| Current - Average Rectified (Io) | 1A |
| Mounting Type | Through Hole |
| Capacitance @ Vr, F | 25pF @ 12V, 1MHz |
| Current - Reverse Leakage @ Vr | 500nA @ 600V |
| Supplier Device Package | DO-204AC (DO-15) |
| Voltage - DC Reverse (Vr) (Max) | 600V |
| Diode Type | Standard |
| Detailed Description | Diode Standard 600V 1A Through Hole DO-204AC (DO-15) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Voltage - Forward (Vf) (Max) @ If | 1.2V @ 1A |
| Operating Temperature - Junction | -65°C ~ 175°C |
